Yuken Pressure Valves DG02 Pressure Relief Valves

1

Yuken Pressure Valves DG02 Pressure Relief Valves

PILOT OPERATED RELIEF VALVE DA SERIES
Items
DT/DG-01
DT/DG-02
Max Pressure
25Mpa
25Mpa
Max Flow
2L/min
16L/min
Net Weight
1.5kg
1.5kg
To Order
D
G/T
02
1
2
3
1
Direct Type Relief Valves
2
G:Sub-plate Mounting|T:Threaded Connection
3
Size:01/02
4
H:7-25Mpa | C:3.5-14Mpa |B:0.1-7Mpa

11

12

2

1111

3

4

5

6

7

8

9
